Researchers solve 'link discovery' problem for terahertz data networks

Leaky waveguide could help devices find one another on future, high-speed data networks

An illustration of radiation of varying frequencies emanating from a leaky waveguide

By Kevin Stacey
Special to Rice News

When you open a laptop, a router can quickly locate it and connect it to the local Wi-Fi network. That ability, known as link discovery, is a basic element of any wireless network, and now a team of engineering researchers from Rice University and Brown University has developed a way to do that with terahertz radiation, the high-frequency waves that could one day make for ultrafast wireless data transmission.

An illustration of radiation of varying frequencies emanating from a leaky waveguide
Radiation of varying frequencies emanate from a leaky waveguide at different angles. This rainbow of frequencies is the basis for a link discovery system for future terahertz data networks. (Image courtesy of Mittleman Lab/Brown University and Knightly Lab/Rice University)

Because of their high frequency, terahertz waves can carry hundreds of times more data than the microwaves used to carry data today. But that high frequency also means that terahertz waves propagate differently than microwaves. Whereas microwaves emanate from a source in an omnidirectional broadcast, terahertz waves propagate in narrow beams.

"When you're talking about a network that's sending out beams, it raises a whole myriad of questions about how you actually build that network," said Daniel Mittleman, a professor in Brown's School of Engineering. "One of those questions is how does an access point, which you can think of as a router, find out where client devices are in order to aim a beam at them. That's what we're thinking about here."

In a paper published in Nature Communications, a team from Mittleman's lab and the lab of Rice's Edward Knightly, the Shaefor-Lindsay Professor of Electrical and Computer Engineering, showed that a device known as a leaky waveguide can be used for link discovery at terahertz frequencies. The approach enables link discovery to be done passively and in one shot.

The concept of a leaky waveguide is simple. It's just two metal plates with a space between them where radiation can propagate. One of the plates has a narrow slit cut into it, which allows a little bit of the radiation to leak out. This new research shows the device can be used for link discovery and tracking by exploiting one of its underlying properties: that different frequencies leak out of the slit at different angles.

"We input a wide range of terahertz frequencies into this waveguide in a single pulse, and each one leaks out simultaneously at a different angle," said Rice graduate student Yasaman Ghasempour, a co-author on the study. "You can think of it like a rainbow leaking out, with each color represents a unique spectral signature corresponding to an angle."

Edward Knightly
Edward Knightly

Now imagine a leaky waveguide placed on an access point. Depending upon where a client device is relative to the access point, it's going to see a different color coming out of the waveguide. The client just sends a signal back to the access point that says, "I saw yellow," and now the access point knows exactly where the client is, and can continue tracking it.

"It is not just about discovering the link once," Ghasempour said. "In fact, the direction of transmission needs to be continually adjusted as the client moves. Our technique allows for ultrafast adaptation, which is the key to achieving seamless connectivity."

The setup also uses a leaky waveguide on the client side. On that side, the range of frequencies received through the slit in the waveguide can be used to determine the position of the router relative to the local rotation of the device — like when someone swivels their chair while using a laptop.

Mittleman says that finding a novel way to make link discovery work in the terahertz realm is important because existing protocols for link discovery in microwaves simply won't work for terahertz signals. Even the protocols that have been developed for burgeoning 5G networks, which are much more directional than standard microwaves, aren't feasible for terahertz. That's because as narrow as 5G beams are, they're still around 10 times wider than the beams in a terahertz network.

"I think some people have assumed that since 5G is somewhat directional, this problem had been solved, but the 5G solution simply isn't scalable," Mittleman said. "A whole new idea is needed. This is one of those fundamental protocol pieces that you need to start building terahertz networks."

Additional co-authors include Rabi Shrestha and Aaron Charous, both of Brown. The research was supported by Cisco, Intel and the National Science Foundation.

— Kevin Stacey is the senior writer for the physical sciences at Brown University.
